360° 6T V-TH Kontur Kupferrohr Radialpresse Handwerkzeuge Hydraulik Presszange

Spezifikationen
Farbe: Gelb
Material: Kohlenstoffstahl, CR45 Stahl, Stahl, Gummi
Oberflächenbehandlung: Wärmebehandlung, Schwärzen Prozess, Schmieden Prozess, Knurling Prozess
V-Shaped Matrizen 'Größen: 12mm/0.5inch; 15mm/0,6inch; 18mm/0,7inch; 22mm/0,9inch; 28mm/1,1inch
TH-Shaped Matrizen' Größen: 16mm/0.6inch; 20mm/0,8inch; 26mm/1,0inch; 32mm/1,6inch
Manuelle hydraulische Pumpe Max Kompression: 700kg/cm² (Ölverbrauch: 2.3cc)
Manuelle hydraulische Pumpe Min Kompression: 20kg/cm² (Ölverbrauch: 13cc)
Hydraulische Zylinder Max Kapazität: 150cc
Hydraulische Schlauchlänge: 113cm/44.48inch
Flexible Grifflänge: 33.5cm/13.18inch
Hydraulische Zange Kompression: 6 Tonnen
Bruttogewicht: 8,2kg/18,07lbs
Nettogewicht: 7,7kg/16,97lbs
Hydraulische Zange Größe: 26*9cm/10.23*3.54inch
Manuelle hydraulische Pumpe Größe: 31*10cm/12.2*3.93inch
Paket Größe: 37.5*22.5*16cm/14.76*8.85*6.29inch Paket enthalten
1*Hydraulische Zange
1*Manuelle Hydraulikpumpe
9*stirbt
1*Englisch Handbuch
Alles Zubehör zur Montage
Anmerkungen
1. Die hydraulische Zange kann nicht gut verwendet werden, wenn das Rohrabstandsmaß sehr kurz ist.
2. Bitte erlauben Sie den leichten Farbunterschied, der durch das Aufnahmelicht und 1-3cm Fehler aufgrund der manuellen Messung verursacht wird, und stellen Sie sicher, dass Sie nichts dagegen haben, bevor Sie bestellen.

Description

Are you having trouble crimping the pipes? Do you want to improve your working efficiency? You mustn’t miss our hydraulic tool! Our hydraulic tool includes a forged and rotary hydraulic plier head, a manual hydraulic pump, and a long rubber hydraulic hose, which is durable and sturdy. Also, it has 9 different-sized dies to replace, which can incredibly improve your work efficiency.

Key Features

Durable and Sturdy: The detachable and forged plier head is made of carbon steel, and the thickened CR45 steel dies combine heat treatment and blackening process, providing good long-term performance.

High Working Efficiency: The compression of the hydraulic plier is 6 tons. Also, the manual hydraulic pump is equipped with a pressure knob, which has a max compression of 700kg/cm² and is very efficient for crimping work.

Optional Dies: The nine different sizes of V-shaped and TH-shaped dies are in the package for you to choose and replace. Also, the circular or hexagonal confining pressure can meet your various demands.

Flexible Design: The plier head can rotate 360°, which allows you to adjust the angle of the plier head flexibly and make your work more convenient. It is a good helper for narrow spaces and tees.

Labor Saving: Our hydraulic crimping tool is designed with a hydraulic cylinder, unlike similar hand tools that rely on leverage and hand force so that one person is enough to make leak-free connections.

Easy to Carry: It can be detached and weighs 16.97 pounds, which makes it easy to carry anytime and anywhere.

Easy Installation: The hydraulic tool is pre-installed, and you only need to spend a little time and effort to connect the hydraulic plier and manual hydraulic pump, enjoying a sense of achievement!

Protective Packaging: This product comes in a custom sponge that resists common compression and falls to prevent product damage in transit.

Details

Long Hydraulic Hose: The hose has a length of 44.48 inch and can connect the hydraulic plier and manual hydraulic pump, offering easy operation.

Flexible Handle: The prolonged handle is wrapped with rubber and the length is 13.18 inches, offering effort-saving and slip prevention.

Two Small Black Buttons: They are on the plier head surface, which can help you fix and disassemble the dies easily.

Pressure Knob: It is on the manual hydraulic pump, which can be adjusted manually according to your needs. Adjust it clockwise to the "on" position before crimping and adjust it anticlockwise to the "off" position after finishing crimping.

Dust Cap: It can prevent dust, water, oil, etc. from entering the hydraulic tool while minimizing the need for daily

maintenance as much as possible.

Plier Head Lever: It can help you open the plier head to replace dies easily and quickly.

Application

This hydraulic tool is suitable for crimping aluminum pipe, PEX pipe, PB pipe, copper pipe, stainless steel sleeve, etc. It also can be applied for domestic water installation, heating installation, gas installation, electricity repair, etc.

Specifications

Color: Yellow

Material: Carbon Steel, CR45 Steel, Steel, Rubber

Surface Treatment: Heat Treatment, Blackening Process, Forging Process, Knurling Process

V-Shaped Dies' Sizes: 12mm/0.5inch; 15mm/0.6inch; 18mm/0.7inch; 22mm/0.9inch; 28mm/1.1inch

TH-Shaped Dies' Sizes: 16mm/0.6inch; 20mm/0.8inch; 26mm/1.0inch; 32mm/1.6inch

Manual Hydraulic Pump Max Compression: 700kg/cm²(Oil Consumption: 2.3cc)

Manual Hydraulic Pump Min Compression: 20kg/cm²(Oil Consumption: 13cc)

Hydraulic Cylinder Max Capacity: 150cc

Hydraulic Hose Length: 113cm/44.48inch

Flexible Handle Length: 33.5cm/13.18inch

Hydraulic Plier Compression: 6 Tons

Gross Weight: 8.2kg/18.07lbs

Net Weight: 7.7kg/16.97lbs

Hydraulic Plier Size: 26*9cm/10.23*3.54inch

Manual Hydraulic Pump Size: 31*10cm/12.2*3.93inch

Package Size: 37.5*22.5*16cm/14.76*8.85*6.29inch

Package Included

1*Hydraulic Plier

1*Manual Hydraulic Pump

9*Dies

1*English Manual

All Accessories for Assembly

Notes

1. The hydraulic plier can't be used well if the pipe distance dimension is very short.

2. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order.
