Betonschüttelmesser, Benzinbetonkompressor für Schlammbetonbelagen, Brückenbelagen, Ebenensuche, 4-Takt 35,8 cc, 900 W

Description

This concrete vibrating leveling machine can be paired with a ruler to scrape on the concrete floor to make the concrete surface smooth. The machine vibration energy is transferred from the surface to the inside through the flat chassis to vibrate the concrete. The effect of vibration reduces air gaps and creates a better density-concrete floor. It is more convenient than traditional floor rulers and saves time and effort.

Key Features

Build to Last:  It is made of high-class aluminum, which is wear-resistant, corrosion-resistant, and durable, ensuring a long service life.

Powerful Motor: The vibration leveling machine is driven by a 900W 4-stroke motor, which runs smoothly and has low fuel consumption, which provides sustained strong motivation for your work and greatly boosts the quality of the project.

User-friendly Design: The humanized switch and dual-handle design allow you to flexibly operate and control this product. The gasoline-driven design also overcomes the weakness of traditional electric drives being limited by the length of the power line, making your operation easy.

High Safety: Uniform cooling holes on the body can ensure the smooth operation of the product as well as safety when using it, and the emergency stop switch can let you use it more reliably.

High-efficiency: The 4-stroke engine with large displacement (35.8cc),  frequency (9500-10000 times/minute) and high excitation force (573 lbs) provides strong power for the machine, and the sturdy drive shaft improves the transmission efficiency for fast concrete leveling.

Thoughtful Design: The soft handle with anti-slip texture is positioned correctly and can rotate 360 ° to meet your needs, making the product easy to push without bending, thus saving time and effort.

Ideal Gift: Thanks to its powerful function and practicality, you can give it to your friends or colleagues as a Christmas, or Thanksgiving gift.

Customer Service: We aim to provide quality products and services. If you have any problems, please feel free to contact us. We will reply and solve the problem for you as soon as possible.

Details

Oil Tank: The 0.17Gal capacity of the visual fuel tank avoids the need for frequent gasoline refills and makes it easy for you to refill in a timely manner.

Dumping Blocks & Support Legs: A larger, thicker dump block and a support leg make for a more durable, and enhance its stability.

Fully Enclosed Shaft: The fully enclosed hollow and thickened closed shaft prevents dust and concrete from getting into the product and prolongs the service life.

Application

It is suitable for vibrating cement concrete pavement, bridge decks, and precast concrete slabs with large areas and small thicknesses, such as construction sites of houses, tunnels, bridges, etc.

Specifications

Material: Aluminum

Color: Silver, Black + Red

Assembly Required: Yes

Mounting Type: Floor Standing

Cooling Mode: Air-cooled

Start Method: Pull Start

Engine Type: 35.8cc 4-stroke Gasoline Engine

Gasoline Type: Any Model Can Be Used

Power: 900W

Frequency: 9500-10000 Times/Minute

Handle Rotation Angle: 360°

Suitable Ruler Length: 1-5m/3.28-16.4ft

Suitable Ruler Width: 14-18cm/5.5-7in

Exciting Force: 260kg/573lbs

Gross Weight: 13.8kg/30.42lbs

Net Weight: 13.11kg/28.9lbs

Product Size: 85*51*82cm/33.46*20.08*32.28in

Package Size: 60*40*40cm/23.62*15.75*15.75in

Fuel Tank Capacity: 0.65L/0.17gal

Package Included

1* Concrete Vibration Leveling Machine

Notes

1. Please check the screws before use. Please change the lubricating oil(not included) regularly.

2. Please note that the product does not include a ruler.

3. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order.
