Kabel-Detektor Leitungssuchgerät Kabelsucher Leitungssucher Cable Tracker Finder,LCD-Display Kabeltester Leitungsfinder MY6818 für Holzbolzen Netzkabel und Metallleitung

Description

This cable detector is made of premium materials to ensure its durability. Its powerful functionality, wide testing range, high measurement accuracy, and automatic testing mode can help you improve detection efficiency. The thoughtful flashlight function allows you to continue working even in the dark. With this practical product, you don't need to take risks in construction.

Key Features

Build to Last: It is mainly made of premium ABS, which is wear-resistant, rust-resistant, impact-resistant, strong, and durable, effectively protecting internal components and extending service life.

Excellent Performance: The sensitive detection head allows it to accurately locate breakpoints, short-circuit points, and insulation fault locations in cables, quickly identifying the problem. The transmitter has an AC/DC voltage measurement function with a wide detection range, which can measure 12-400V AC and DC voltage linearly. Moreover, the thoughtful flashlight function makes it convenient for you to work in the dark.

User Friendly: It supports automatic test mode, which can automatically complete a series of tests in accordance with preset procedures to improve test efficiency.  It also supports automatic and manual mode switching at will to enhance operational sensitivity. The fault warning function can issue an alarm immediately when abnormal conditions are detected, which is convenient for operators to handle in time.

Simple Operation: The LCD display can clearly display measurement results and operation prompts, making it easy to read and understand. Both the transmitter and receiver display the power level, code, battery voltage, type and value of voltage detected, etc. The operation panel is simple and intuitive, with sensitive buttons that allow you to quickly get started and operate.

Easy to Carry and Store: The compact receiver(9.45*3.07*1.46in) and transmitter(7.36*3.46*1.57in) are lightweight (2.8 lbs), easy to store and carry, and a portable storage bag with mesh pockets can store them in an orderly manner to prevent loss.

Easy to Clean: The dust and stains on its smooth shell can be easily wiped off with a cloth.

Ideal Gift: This high-performance and practical instrument is a great gift for family, friends, and colleagues, allowing them to enjoy a more convenient life.

Customer Service: We aim to provide quality products and services. If you have any problems, please feel free to contact us. We will reply and solve the problem for you as soon as possible.

Details

Round Edges: The rounded corners make it more comfortable to hold, and can protect your hands, increasing the safety of use.

Shoulder Strap: The practical shoulder strap allows you to easily carry it to any workplace.

Mute Function Key: In special situations such as hospitals, this feature ensures that the detection operation does not disturb anyone.

Application

It is suitable for various communication cable construction, power cable construction, building pipeline construction, maintenance work of communication cables, power supply lines, and electric heating lines.

Specifications

Color: Green+Black

Material: ABS

Power Source: Battery Powered(Included)

Display: LCD

Transmitter:

Output Signal: 125 kHz

External Voltage Identification Voltage Range: DC 12 ~ 400V ± 2.5%, AC 12 ~ 400 V (50 ~ 60 Hz) ± 2.5%

Temperature Measurement Accuracy: ±2.5%

Dielectric Strength For External Voltage: Max. 400 V AC/DC

Overvoltage Category: Cat Iii 300V

Pollution Degree: 2

Battery: 2*9V Batteries (Included)

Transmitter Energy Consumption:

Minimum Current: About 31mA

Maximum Current: About 115mA

Fuse: F 0.5 A 1000 V, 6.3*32mm/0.25*1.26 in

Operating Temperature: -10 ~ 50℃/14-122℉, Maximum Relative Humidity 80% (Non-Condensing)

Storage Temperature: -20~60℃/-4-140℉, Maximum Relative Humidity 80% (Non-Condensing)

Height: Up to 2000m/6562ft

Receiver:

Track Depth: Track Depth Depends on Media and Specific Application

Cable Positioning Method:

Monopolar Application: About 0-2m/0-6.56ft

Bipolar Application: About 0-0.5m/0-1.64ft

Independent Oil Return Pipe: Up to 2.5m/8.2ft

Power Supply Voltage Detection: About 0-0.4m/0-1.31ft

Battery: 6*1.5V AAA Batteries (Included)

Receiver Energy Consumption:

Minimum Current: About 32mA

Maximum Current: About 89mA

Operating Temperature: -10 ~ 50℃/14-122℉, Maximum Relative Humidity 80% (Non-Condensing)

Storage Temperature: -20~60℃/-4-140℉, Maximum Relative Humidity 80% (Non-Condensing)

Height: Up to 2000m/6562ft

Transmitter Size: 18.7*8.8*4cm/7.36*3.46*1.57in

Receiver Size: 24*7.8*3.7cm/9.45*3.07*1.46in

Packing Size: 30*20*9cm/11.81*7.87*3.54in

Gross Weight: 1.4kg/3.09 lbs

Net Weight: 1.27kg/2.8 lbs

Package Included

1*Cable Locator Transmitter

1*Cable Locator Receiver

2*Clips

2*Test Leads

2*Test Pens

2*9V Batteries

6*1.5V AAA Batteries

1*Ground Rod

1*Storage Bag

1*Shoulder Strap

1*English Manual

Notes

1. Please check what kind of wire you want to locate. It is only for single-strand wire, or double-strand wire in parallel, not for multistrand wire!

2. Please do not use live circuits to avoid damaging the tester! This device is mainly to locate non-energized cable, or low-voltage situations less than 24V.

3. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order.
