Mini scie de table professionnelle multifonctionnelle avec lame relevable avec couteau à onglet, 300 W, Power DIY, travail du bois, outil fait main, doré

Description

Do you like to do crafts? Do you want to create a wooden craft by yourself? With this mini table saw, you can make a unique craft gift for your family, friends, and loved ones! It is suitable for various small objects sanding and drilling, etc. It allows you to sand finer and safer.



Key Features

Thoughtful Design: The height of the saw blade can be raised and lowered (turn the wrench clockwise to raise, and counterclockwise to lower), and the cutting thickness is 0-1.14in. You can control the height of the saw blade according to your needs.



Convenient Storage: The product is small in size (14.17*9.45*7.48 inch) and fully functional. It will not take up too much storage space, which is so convenient.



High-quality Materials: The panel of this mini table saw is made of high-quality aluminum alloy, while the housing is made of high-quality iron. These strong, sturdy materials make this product robust and durable.



Accurate Scale: This scale on the panel uses the laser scale process, so it is more accurate. The scale is integrated with the table, so it is also more convenient to use.



High Safety:  Large table saws are clumsy and unsafe for cutting small objects and may cause injury to you. This table saw is flexible and compact, greatly reducing the chances of accidental injury.



Multi-purpose: This mini table saw can be used for DIY crafts, small woodworking workshops, interest development, creative research, and development, you can use it to give full play to your creativity and imagination, wandering in the sea of DIY creation.



Powerful Power: It uses a 300W high power motor to provide a speed of 9000 rpm, providing you with high-speed and power cutting.



Anti-slip and Shock Absorption: The bottom of the machine is made of silicone feet, which can effectively prevent slipping and shock absorption. This further ensures the safety of the machine and effectively reduces the noise.



Details

Angle Ruler: This angle ruler (0-90°) can be adjusted and marked at will. It can meet your multi-angle cutting and grinding.



Protective Plate: The protective plate adopts a transparent design, which can play a protective role and will not block the view, so it is easy for you to operate.



One-touch Switch: The simple one-touch switch design makes it easy to switch on and off, even for novices.



Drill Chuck: This drill chuck can be adjusted for tightness in the range of 0.06-0.39inches by rotation, so it can meet your various processing needs.



Heat Sink Hole: The machine body is equipped with a heat sink hole, which can prevent the failure problem caused by the excessive temperature of the machine, and can make the interior of the machine well-ventilated to avoid dust accumulation.



Flexible Shaft: The product adopts a flexible shaft design, which can make you more convenient and free to control the direction and position of carving.



Use of Four Saw Blades

1. Diamond Saw Blade: It is used to cut honey wax, agate, small jade, pebble, crystal stone, etc.

2. High Speed Hacksaw Blade: It is used to cut plastic, chopsticks, PVC and so on.

3. Grinding Wheel Saw Blade: It is used to cut small steel pipes, small steel plates, stainless steel, small aluminum plates, etc.

4. Multi-function Saw Blade: It is used to cut thick materials such as wood boards, acrylic boards, ABS boards and bakelite boards.



Bakelite Milling Operation Instructions

1. Milling slot: Install the cushion and milling cutter, adjust the milling cutter to the right position, and you can start working.

2. Punching: Install the bakelite wash cushion and milling cutter, and press the wood block down against the cushion, and the aperture can be adjusted according to the size of the milling cutter.

3. Milling edge: Install the bakelite milling cushion and milling cutter, align them with the scale, and you can start milling the edge.



Saw Blade Installation Instructions

1. Remove the 4 screws from the table first, loosen the saw blade clamp with a wrench, and take off the outer saw blade clamp.

2. After installing the saw blade, tighten it to be ready for use. (Counterclockwise rotation is loosening the saw blade.)



Drill Chuck Installation Instructions

1. Fix the connecting rod and joint first

2. Tighten the screws with a wrench



Application

This mini table saw can be used for cutting, grinding, polishing, carving, and punching PCBs, small wooden sticks, acrylic, copper tubes, thin wooden boards, aluminum alloys, etc.



Specification

Material: Iron, Aluminum Alloy

Power: 300W

Color: Gold

Voltage: 220V

Plug: EU Standard

Working Voltage: 12V-24V

Push Ruler Angle: 0-90°

Cutting Thickness: 0-29mm/0-1.14in

Collet Range: 1.5-10mm/0.06-0.4in

Motor Speed: 9000rpm

Saw Blade Aperture: 16/20mm/ 0.63/0.79in

Package Size: 30*27*21cm/ 11.81*10.63*8.27 in

Product Size: 24*20*13cm/ 9.45*7.87*5.12 in

Net Weight: 5kg/11.02 lbs

Gross Weight: 5.5kg/12.13 lbs



Package Included

1 * Mini Table Saw

1 * Instruction Manual (Chinese & English)

1 * Diamond Saw Blade

1 * High-speed Hacksaw Blade

1 * Grinding Wheel Saw Blade

1 * Multi-function Saw Blade

All Accessories for Installation



Notes

1. This table saw is a small table saw, and can only cut small parts, not an industrial table saw. Please see the parameters before you buy.

2. Please allow the slight color difference caused by the shooting light and the 1-3cm error due to manual measurement. Please make sure you do not mind before you order.
