Achsmessplatte, Tragkraft über 3 Tonnen, Einstellplatte Drehplatte für Fahrzeug Achseinstellung, Spurvermessung und Radvermessung mit 360-Grad-Drehung und Klaren Skalen zur präzisen Einstellung

Description

The wheel alignment turn plates are one of the important components of the four-wheel alignment instrument, which can facilitate the measurement of steering angle and ensure adjustment accuracy as the necessary supporting product during the four-wheel alignment. Meanwhile, as technical equipment in four-wheel alignment, the wheel alignment turn plates have become a good assistant for improving the quality and efficiency of automotive maintenance due to their excellent measurement accuracy, wide applicability, sturdy and durable structure, and simple operation process.

Key Features

Durable & Sturdy: The rubber transition blocks and thrust pads, the thickened magnesium-aluminum alloy material with a die-casting process, and the nylon beads provide greater than a loading-bearing capacity of 6613 pounds (one turn plate) and long-term performance.

Flexible Adaptability: One measures 15.74*15.74*1.96 inches and can fit different tires. Whether standard sedans, high-performance sports cars, or heavy-duty commercial vehicles, they can meet diversified maintenance needs, adapting to a wide range of market needs.

Easy to Carry: Considering the need for movement and storage, they have portable handles, making it easy to move between different workplaces and increasing flexibility.

Simple Maintain: They can be disassembled and cleaned with compressed air when the turn plates don't rotate flexibly, applying the appropriate amount of lubricating grease after cleaning.

Multiple Use: It not only can easily collocate with a four-wheel alignment instrument (excluded) but also can be used individually to fill the groove of the automobile lift.

User-friendly Design: The 360-degree rotation allows you to measure and adjust the steering angle easily and quickly.

Easy to Operate: It can quickly help finish the calibration after connecting with the four-wheel alignment instrument (excluded) and removing latches on the wheel alignment turn plates, effectively shortening vehicle maintenance time and improving work efficiency.

Customer Service: Communication is the best way to solve problems. If you have any problems, please feel free to contact us. We will reply and solve the problem for you as soon as possible.

Details

Latches: They are made of high-quality carbon steel and conveniently fix the turn plates.

Anti-slip Textures: They are on the surface of turn plates and can prevent the tires from slipping.

Clear Scales: They are beside the handles and can provide a detailed angle for adjustment without a computer display.

Application

They can be applied to the automobile lift's groove and the groove size is 15.74 (length) * 1.93 (depth) inches. They can't be used if the groove size is smaller than the size. The following situations can also be used with simple retrofit: the groove length is 400+a mm, and you can put an iron square tube or wood batten (length: a mm; height: 50mm; width: equal to the lifting platform's width) in front of the wheel alignment turn plates; the groove depth is 50+b mm, and you can put an iron sheet (thickness: b mm; the other size is the same as the groove's size) under the wheel alignment turn plates.

Specifications

Color: Grey

Material: Magnesium-aluminum Alloy, Rubber, Nylon, Carbon Steel

Process: Die-casting Process

Loading-bearing Capacity (Single One): Greater Than 3T/6613 lbs

Suitable Groove's Size(Length*Depth): 400*50mm/15.74*1.96inch

Gross Weight: 15.8kg/34.83lbs

Single Net Weight: 4.3kg/9.48lbs

Single Product Size: 40*40*5cm/15.74*15.74*1.96inch

Package Size: 48*41.5*12cm/18.89*16.33*4.72inch

Package Included

2*Wheel Alignment Turn Plates

2*Transition Blocks

2*Thrust Pads

2 Pairs*Latches

Notes

1. Please try to avoid small particles entering the inner disk and they can't be washed with water. The compressed air is available for cleaning.

2. Please allow the slight color difference caused by the shooting light and the 1-3cm error due to manual measurement, and make sure you do not mind before ordering.
