Rohrausklinker, Rohrschneider Ausklinker Tube Notcher Rohrausklinkmaschine 19mm-76mm Rundrohr 0 Bis 50° Rohrausklinkmaschine Ausklinker Tube Pipe Notcher Kunststoffrohrschneider

Description

Do you want to cut tubes more easily and quickly? Then look no further than the pipe and tube notcher made of high-quality iron and stainless steel. The thickened structure provides you with stability and ease of use. And you can cut a variety of tubes with some simple steps!

Key Features

Good Material: This pipe and tube notcher is made of high-quality iron and stainless steel, with strong hardness and good corrosion resistance, so it can be used for a long time.

Adjustable Rotation Angle: It can make round cuts in pipe and tubing of kinds of shapes at any angle from 0-50 degrees flexibly to facilitate your work.

High Portability: With a weight of 21.16lbs, this pipe and tube notcher is light enough to be carried anywhere you want, facilitating your daily use.

Quick Cutting: It has precise grinding saw teeth for smooth and fast cutting, and high efficiency while saving you time and effort.

2-axis Adjustable Pipe Clamp: It has 2-axis adjustable tube clamps, you can offset it vertically by 1-1/2'' from the slot to facilitate your use.

Easy to Use: All you need to do is bolt it to the workbench, or just attach it to the workbench and clamp it in a vise to get started.

Easy to Clean: You can easily clean it without much effort and time because of the smooth surface caused by iron. If there is dust, just wipe it off with a rag.

Customer Service: We aim to provide quality products and services. If you have any problems, please feel free to contact us. We will reply and solve the problem for you as soon as possible.

Details

Polished Stainless Steel Shaft: Its shaft is a 1'' polished stainless steel shaft, the smooth polished surface allows you to easily replace the hole saws, and the stainless steel material makes it very durable.

Thickened Frame: Its frame is 1-1/4 inches thick, allowing it to do an excellent job of cutting while also enhancing its longevity.

Application

It can notch all CNC machined 1/4" thick steel frames. And it may work with an ordinary 1/2 inch hand drill.

Specification

Model: PNM1-1/2 inches

Color: Black, Blue

Material: Iron, Stainless Steel

Capacity: from 3/4" to 3" OD

Diameter between the Pipe Clamps: 19mm/ 0.748in, 76mm/ 2.99in

Rotation Angle: Max. 50°

Frame Thickness: 1-1/4 in

Product Size: 23*20*19cm/ 9.06*7.87*7.48in

Net Weight: 9.6kg/ 21.16lbs

Gross Weight: 10.5kg/ 23.15lbs

Package Included

1 * Pipe & Tube Notcher

Notes

Please allow the slight color difference caused by the shooting light and 1-3 cm error due to manual measurement, and make sure you do not mind before ordering.
